Product model |
S-300-5 |
S-350-12 |
S-350-24 |
S-350-36 |
Input voltage |
AC110/220V |
AC110/220V |
AC110/220V |
AC110/220V |
Output voltage |
DC 5V |
DC 12V |
DC24V |
DC 36V |
Output current |
DC 60A |
DC 29.8A |
DC 15.1A |
DC 9.9A |
Output power |
300 W |
350 W |
350 W |
350 W |
Product size |
215*115*50mm |
215*115*50mm |
215*115*50mm |
215*115*50mm |
Product weight |
1200g |
1200g |
1200g |
1200g |
Product authentication |
CE |
CE |
CE |
CE |
* Price bottom, high reliable, operating temperature bottom, operating temperature - 10℃~+50℃
* The whole world is suitable AC90-250V (47-63Hz) the input voltage, the soft starting current has the suburb to fall the bottom AC input impact.
* The output has the short circuit, the over-load protection, 105%~150% cut-off output, self-recovery, 100% full load aging test.
* DC voltage adjustable range ±10%.
* The start, the rise, maintain the time, 300ms, 50ms, 80ms.
* Insulation strength resistance to pressure; Input output: between 3.5KvAC input and outer covering: between 1.5KvAC output and outer covering: 0.5KvAC one minute.
* The standard of security conforms to GB4943, UL60950, EN60950; The EMC standard conforms to GB9254, EN55015 rank B
